Santa Cruz Tallboy Carbon 29 - GX AXS Reserve - Matt Taupe - 2023

The Tallboy has earned a loyal following amongst those who seek a go-to bike that will hold up to the relentless hammering of "power hour" hot laps or long days in the saddle harvesting the best trails. The highly-refined VPP™ suspension on the Tallboy combines pedaling efficiency and all-out bump-chomping prowess. If ever there was a gravity riders’ XC bike, the Tallboy is it.

• Wheel size: 29-inch
• Front travel: 130mm
• Rear travel: 120mm

Fully dialed at every size: Proportional Geometry and frame stiffness tune

Chainstay length and seat angle are matched to the frame size (STA steepens and rear centre grows as frame size increases) so that every rider, no matter what height, gets the same balance of geometry and handling characteristics.

We tailor stiffness for every size to make sure everyone gets the same ride quality. Bigger riders means greater stresses on larger frames, but that's remedied with our size-specific frame stiffness tunes.

SPECIFICATIONS

• Frame Material Carbon Fiber
• Frame Material Details Carbon C front and rear triangles; molded chainstay, seatstay, and down tube protection
• Rear Travel 120mm
• Rear Shock FOX FLOAT DPS Performance Elite, 190mm x 45mm
• Fork RockShox Pike Select+
• Fork Travel 130mm
• Head Tube Diameter Tapered, 1.125" top, 1.5" bottom
• Headset Cane Creek 40 IS integrated, IS41 upper, IS52 lower
• Handlebar Santa Cruz 35 Carbon, 800mm width
• Stem Burgtec Enduro MK3, 42mm length
• Grips Santa Cruz House
• Brakes SRAM G2 RS, 4-piston, Avid CenterLine 180mm rotors
• Brake Levers SRAM G2 RS
• Drivetrain 1x
• Shifters SRAM GX Eagle AXS Controller, 12-speed, electronic wireless
• Front Derailleur None
• Rear Derailleur SRAM GX Eagle AXS, 12-speed, electronic wireless
• ISCG Tabs ISCG05
• Chainguide None
• Cranks SRAM GX Eagle DUB
• Chainrings SRAM GX Eagle, 32 tooth
• Bottom Bracket SRAM DUB, 73mm English/BSA threaded
• Pedals None
• Chain SRAM GX Eagle, 12-speed
• Cassette SRAM GX Eagle XG-1275, 12-speed, 10-50 tooth
• Rims Reserve 30 SL Carbon, 28 hole
• Hubs Industry Nine 1/1, 110x15mm Boost front with Torque Caps, 148x12mm Boost rear with XD driver
• Tires Front: Maxxis Dissector, 3C MaxxTerra compound, EXO casing, TR, 29" x 2.4" WT
• Rear: Maxxis Rekon, 3C MaxxTerra compound, EXO casing, TR, 29" x 2.4" WT
• Saddle WTB Silverado Medium, CroMo rails
• Seatpost RockShox Reverb Stealth dropper
• Seatpost Diameter 31.6mm
• Seatpost Clamp Single bolt, 36.4mm
• Rear Dropout / Hub Dimensions 148x12mm Boost
• Max. Tire Size 29" x 2.5"
• Bottle Cage Mounts One inside front triangle
