Ritchey Outback Gravel Frameset - Gray-White - 2023



While some cyclist enjoy working hard, pushing limits and flying down descents at blistering speeds, embracing the hard hitting adrenaline, many love the simplicity and serenity that comes with the open road and beauty of mother nature. Tom Ritchey himself spends the majority of his riding throughout the year off-road, soaking in the natural beauty that surrounds him.

Building upon the already well established legacy of the Outback platform, the V2 boasts several practical and adaptable features that offer riders the ability to chase epic ride experiences beyond the end of the road.

Features:

  • Heat-treated, triple-butted Ritchey Logic tubeset fully TIG welded
  • Ritchey Carbon Adventure Fork with multi-purpose rack and fender mounts
  • Flat-mount brake compatible with thru axle front and rear
  • Clearance for up to 700c x 48mm & 650b x 2.0" tires
  • External cable routing
  • Includes thru axles and headset
  • Frame Specifications:
  • Frame Material: Heat-Treated, Triple-Butted Ritchey Logic Steel Tubing
  • Wheel & Tire Compatibility: 700c x 48mm or 650 x 2.0"
  • Frame Max Spacing: 58mm
  • Rear Axle Spacing: 12 x 142mm (Alloy Thru-Axle Included)
  • Brake Compatibility: Flat-Mount, 140mm (160mm Max, Adapters Sold Separately)
  • Frame Flat-Mount Bracket Height: 10mm
  • Headtube Size: 1-1/8"
  • Headset (Upper): IS42/28.6mm (WCS Headset Included)
  • Headset (Lower): IS42/30mm (WCS Headset Included)
  • Stack Height: 16mm
  • Front Derailleur Clamp Size: 28.6mm (2.5Nm Max Torque, Not Included)
  • Rear Derailleur Hanger Type: Replaceable (Stainless Steel)
  • Seat Tube Size: 27.2mm (Integrated Seat Collar, 6Nm Max Torque)
  • Bottom Bracket: 68mm (English Thread)
  • Chainring Compatibility: 1x (36 - 46T) or 2x (46/30T to 50/34T)
  • Cable Routing: External
  • Mounting Options: 3 Bottle Mounts, Rack & Fender Mounts
  • Frame Weight: 2175g (L w/o Thru-Axle)

Fork Specifications:

  • Fork Material: Carbon
  • Steerer Type: 1-1/8" Straight (Integrated 45° Crown Race)
  • Steerer Length: 300mm
  • Axle to Crown Measurement: 393mm
  • Front Axle Spacing: 12 x 100mm (Alloy Thru-Axle Included)
  • Rake/Offset: 50mm
  • Fork Max Load: 3000g (Per Side)
  • Fork Weight: 445g (uncut without Thru-Axle)
