GRAVEL FROM THE GROUND UP

Designed from the ground up for gravel, the Terra isn’t a repurposed road bike or a slimmed-down mountain bike. It’s built to add comfort to your road adventures, help you finally discover where that dirt trail leads, or even extend your trips overnight. There’s a wide world out there, and Terra is ready to explore it with you.

Tire Clearance

The Terra can be mounted with 700c x 45 tires for speed and efficiency on dirt roads, or with 650b x 50 treads for extreme durability and high-volume comfort if you need a bit more traction.

Drivetrain Compatibility

Designing our frame from the ground up gave us the opportunity to tackle a problem that exists in many gravel frames—providing a range of drivetrain options without compromising tire clearance.

Lockr

Our Carbon frame offers a storage area inside the downtube, hidden behind the bottle cage, where there is space for the tube, pump, or CO2 cartridge, as well as a selection of tools.

Specifications

Frameset

• Frame: Orbea Terra Hydro disc, hydroformed triple-butted aluminum, HS 1.5", PF, Thru Axle 12mm x 142mm rear, thread M12x2 P1, DT internal cable routing, 27.2mm seat tube, MMS system
• Fork: Orbea Terra ICR, full carbon, 1-1/8" - 1.5" tapered head tube compatible, Thru axle 12x100mm, thread M12x2 P1
• Headset: FSA 1-1/2" Integrated Aluminum Cup

Drivetrain

• Crankset: SRAM Apex 1 DM Dub Wide 40t Steel
• Shifters: SRAM Apex
• Cassette: SRAM PG-1231 XPLR 11-44t 12-Speed
• Rear Derailleur: SRAM Apex XPLR 12s
• Chain: SRAM Apex 12-Speed

Cockpit

• Handlebar: OC Gravel GR31-R, Rise 15, Reach 70, Drop 110
• Stem: OC Road Performance RP21, -6º
• Brakes: SRAM Apex Hydraulic

Wheels

• Wheels: Alloy, Tubeless, 700c, 21c
• Tires: Vittoria Terreno Dry Gravel 700x38c
• Front Wheel Axle: Orbea Thru Axle 12x100mm M12x2 P1 Solid
• Rear Wheel Axle: Orbea Thru Axle 12x142mm M12x2 P1 Solid inner threaded

Components

• Seatpost: SP 0.2 Carbon, 27.2mm, Setback 20
• Saddle: Prologo Akero AGX STN size 155mm

Accessories

• Mudguard:
• Handlebar Tape: Orbea Eva
