THE ESSENCE OF ADVENTURE

Your bike should match your vision of the ride, adapting to whatever adventure your trail takes you on. Occam SL opens up big mountain adventures and long distances. Light and efficient, the fast trail geometry and efficient suspension bring control and flow to your adventures.

Lock On The Go

Remote lockout comes to trail bikes with Occam SL. Locking and unlocking the suspension quickly becomes second nature, and once you have tried it, you won't want to live without it.

Stealthy and Protective

Cables are fully guided from the rear to LOCKR, and from there, it's easy to reach the head tube if you ever need to replace a cable outer.

Carbon Shock Extender

The carbon shock extender maximizes rigidity and minimizes weight. It is one of the features that make the Occam SL so light while also enhancing handling and pedaling efficiency.

Specifications

Frameset

• Frame: Orbea Occam OMR. Concentric Boost 12x148 rear axle. Pure Trail geometry. Internal cable routing. Asymmetric design. 29" wheels
• Shock: Fox Float Performance Remote Push-lock Evol custom tune 210x50mm
• Fork: Fox 34 Float Performance 140 Remote Push-lock QR15x110
• Headset: Alloy 1-1/2", Black Oxidated Bearing

Drivetrain

• Crankset: Race Face Aeffect 32t
• Shifters: Shimano SLX M7100 I-Spec EV
• Cassette: Shimano CS-M7100 10-51t 12-Speed
• Rear Derailleur: Shimano XT M8100 SGS Shadow Plus
• Chain: Shimano M6100

Cockpit

• Handlebar: OC Mountain Control MC30, Rise20, Width 800mm
• Stem: OC Mountain Control MC20, 0º
• Computer Mount: OC Computer Mount CM-05, Garmin/Sigma
• Brakes: Shimano M6100 Hydraulic Disc

Wheels

• Wheels: Race Face AR 30c Tubeless Ready
• Tires: Schwalbe Wicked Will Evo TLE, 29x2.40 Super Race, Speed Grip, Addix, Brown

Components

• Seatpost: OC Mountain Control MC21, 31.6mm, Dropper
• Saddle: Fizik Terra Ridon X5 145mm
• Grips: OC Lock On
• Remote Lockout: OC Squidlock MC20 Remote, Dropper, Suspension 2 Pos

Accessories

• Storage: Accessories Containers
