Kona Remote 130 29 - Gloss Metallic Pewter - 2022

The Remote 130 has been spotted ripping through the forests from North Vancouver, down to Bellingham, across deserts, and all over the world. A little bit Process 134, a little bit Remote 160, it strikes a perfect harmony between an all-mountain trail bike and fully capable pedal-assist electric mountain bike. A sturdy aluminum frame holds a Shimano motor and battery. Supple suspension keeps the big hits feeling supported and the rough stuff feeling smooth. 29" wheels are wrapped in ultra-sticky rubber, ensuring excellent traction. Whether cramming in an after-work ride, or out for a multi-hour excursion, the Remote 130 is as versatile as the bikes that inspired it.

KONA 6061 ALUMINUM
Kona 7005 and 6061 Aluminum alloys are used extensively throughout our fleet of mountain and asphalt bicycles. A tough, durable, light alloy, both Kona 7005 and 6061 deliver fantastic, reliable performance that lasts for thousands of rides. Much of our 7005/6061 tubing is butted and/or formed, meaning the tubing's wall thickness can be increased or decreased, as well as shaped, so we can fine-tune a particular frame's strength and ride characteristics depending on its intended application.

INTERNAL HEADSET
Bearing cups are actually pressed into the frame and are easily removable. An internal headset also reduces stack height, so the height of the stem and bars are more adjustable, giving the rider the best fit possible.

TAPERED HEAD TUBE
More girth at the bottom of the head tube better distributes shock force, prolonging the bearing life of the headset itself and eliminating brake shudder, while providing confident steering performance. The inherent strength of its triangular design also means a stronger steering position and improved balance, giving the rider more control in rough terrain. A zero-stack, tapered head tube also puts strength where the load is going—into the lower headset cup—maximizing bearing durability where it's needed.

TUBELESS COMPATIBLE RIMS
Tubeless rims allow for tires with more puncture resistance; the ability to run lower tire pressure, which provides better tire grip on the trail; lower rolling resistance; and weight savings over traditional tube and tire systems.

12x148mm AXLE
12x142mm, 12x148 and 12x157 rear axle standards provide two major advantages to the Kona rider: the 12mm diameter of the rear axle provides the rear hub and frame with a stiff interface, while the 142/148/157mm outer diameter of the hub allows the wheel to be quickly and properly positioned in the frame before the rear axle is inserted.

BEAMER INDEPENDENT SUSPENSION
Built to be off-the-top progressive, Beamer Independent Suspension helps the bike to stay higher in the travel and recover from hits more quickly. The Operators are instilled with what our product managers like to call "pure shock movement," whereby the shock is protected from side load. Designed to be highly tuneable and extremely durable, the Beamer IS is our version of greased lightning.

FEATURES:

• Travel: 130mm rear and 140mm front suspension travel, blending the best attributes of all-mountain and e-MTB capabilities.
• Motor: Shimano E7000, offering up to 20 MPH of pedal assist with customizable power settings.
• Battery: Shimano 504Wh for reliable power throughout your ride.
• Brakes: Shimano Deore with 203mm rotors front and 180mm rotors rear, ensuring strong and consistent stopping power.
• Wheels and Tires: 29" wheels with ultra-sticky rubber for excellent traction on various terrains.
• Suspension: Equipped with Beamer Independent Suspension (KIS) for a smooth and progressive ride that handles big hits well.

SPECIFICATIONS:

• Frame: Kona 6061 Aluminum Butted, designed for 130mm travel.
• Fork: Fox Rhythm 34 Float, 140mm travel, tapered steerer, 110mm spacing.
• Rear Shock: Fox Performance Float Trunnion.
• Rims: WTB KOM Trail i35 TCS 2.0.
• Hubs:
  • Front: Formula 110x15mm.
  • Rear: Formula 148x12mm.
• Spokes: Stainless Black 14g.
• Tires:
  • Front: Maxxis Minion DHF EXO+ TR 3C, 29x2.5" WT.
  • Rear: Maxxis Minion DHR II EXO+ TR 3C, 29x2.4" WT.
• Crankset: Shimano E8000.
• Chainrings: 36t.
• Shifters: Shimano Deore.
• Rear Derailleur: Shimano Deore.
• Cassette/Freewheel: Shimano Deore 10-51t, 12-speed.
• Chain: Shimano Deore.
• Brakes: Shimano Deore.
• Rotors:
  • Front: Shimano RT66, 203mm.
  • Rear: Shimano RT66, 180mm.
• Brake Levers: Shimano Deore.
• Handlebars: Kona XC/BC 35.
• Grips: Kona Key Grip.
• Stem: Kona XC/BC 35.
• Headset: FSA No.57E.
• Seatpost: TranzX Dropper Internal, 31.6mm.
• Saddle: WTB Volt.
• Pedals: Sold separately.
• Motor: Shimano E7000, 20 MPH assist.
• Battery: Shimano 504Wh.
• Controller/Display: Shimano SC-E7000 Display.
