Ride trails with confidence, control and flat-out fun. This new Ebike has a powerful motor, plush suspension, and intuitive controls that can take your trail adventures to a whole new level.

The SyncDrive Sport 2 motor delivers 75Nm of torque for smooth acceleration and climbing power, even at low speeds on technical trails. FlexPoint rear suspension (125mm travel, plus 140mm up front) gobbles up rocks and other trail obstacles. The RideControl Dash control unit has integrated handlebar support buttons for improved ergonomic control. And a new EnergyPak 625 battery system lets riders push their trail riding adventures further.

Key Performance Factors:

• Powerful pedalling support: The new compact SyncDrive Sport motor has Smart Assist technology and is sonically tuned for smooth, quiet performance. It delivers 75Nm of torque for high power, even at low speeds on technical trails.
• Confident handling: ALUXX SL aluminium frame with 125mm travel FlexPoint rear suspension and larger diameter 29-inch wheels produces a smooth, stable ride on technical trails.
• Long-lasting fun: The new EnergyPak 625Wh battery offers the longest possible range. The integrated battery pack makes charging quick and easy.

Techs & Features:

• ALUXX SL Aluminum Technology: This High-Performance level, state-of-the-art aluminum material is made predominantly from 6011 alloy and delivers best-in-class strength-to-weight ratios. These framesets also feature unique welding technologies for a high-performance ride quality.

• FlexPoint Suspension Technology: A proven “single-pivot” design that uses the flexing action of the chainstay/seatstay junction to produce a lightweight and durable suspension system with 4.7 inches/120mm of rear travel.

• E+ System: E+ System combines electric power with human power to produce a smart, natural and powerful E-bike riding experience. It’s an integrated group of technologies that includes our RideControl control units, EnergyPak battery systems and SyncDrive motors.

• SyncDrive Sport: Innovation, manufacturing expertise and a motor system powered by Yamaha all combine to expand any rider’s abilities. SyncDrive Sport offers three support modes and is equipped on E-bikes that are used for both everyday riding and for more demanding off-road riding. This small mid-drive motor delivers a massive maximum 80Nm of torque and is widely acclaimed for its performance and reliability.

• Smart Assist: All SyncDrive motors have Smart Assist technology, which adjusts the support to match the rider’s needs. By using information from multiple sensors, both rider input and terrain feedback are used to determine the optimal amount of pedaling assistance. SyncDrive is the only e-bike system that utilizes both rider input and terrain feedback. It gives you a smooth, natural riding experience with ample power when you need it, while also conserving power when you don’t need as much.

• EnergyPak Plus: This range extender can boost total capacity by 250Wh. It has all the latest technologies combined with an up-to-date design that fits a select number of bikes. It has smart technology so it automatically turns on when your battery loses power, giving you peace of mind that you can reach your destination.
• Energypak: Giant’s latest EnergyPak battery systems feature streamlined designs that are integrated with the E-bike for a sleek and modern profile. Giant E-bikes offer several different EnergyPak options including the EnergyPak Smart and EnergyPak. Each one is designed to optimize the E-bike experience for a specific style of riding.
• RideControl Dash: This two-in-one unit features buttons to control support modes plus an integrated color display. You can check range, battery level and support mode, along with standard cycling data such as speed and distance without having to another screen to the E-bike. It also has an ANT+ connection so you can connect a heart rate monitor and other fitness devices.

Specifications:

Frame
Frame: ALUXX SL-Grade aluminium, 125mm travel FlexPoint suspension system, 12x148mm thru-axle, UDH hanger
Fork: SR Suntour XCR 34 LO-R, 140mm travel, tapered steerer, Lockout, 110x15 thru-axle
Shock: SR Suntour Raidon R, custom tuned

Electronics
Motor: SyncDrive Sport 2, 75Nm, powered by Yamaha
Battery: EnergyPak Smart 625Wh EnergyPak Plus range extender compatible
Controls: RideControl Dash
Display: RideControl Dash, full colour lcd screen
Charger: EnergyPak 4A smart charger compact

Components
Handlebar: Giant Connect TR Riser 31.8mm
Grips: Giant Tactal single lock-on
Stem: Giant Contact
Seat Post: Giant 30.9mm, 2-bolt Micro Adjustable, alloy
Saddle: Giant Sport
Pedals: Aluminium Platform

Drivetrain
Shifters: Shimano Deore LinkGlide
Front Derailleur: MRP HD2 co-moulded chain guide
Rear Derailleur: Shimano Deore LinkGlide, 10-speed
Brakes: Tektro HD-M745 Orion, 4-piston, hydraulic disc, (F) 203mm, (R) 203mm
Brake Levers: Tektro HD-M745 Orion
Cassette: Shimano LinkGlide, CS-LG400-10, 11-43T, 10-speed
Chain: Shimano, LinkGlide, CN-LG500
Crankset: FSA Comet E-Bike crank arm setFSA MegaTooth Direct-mount 1X steel 36T

Wheels
Rims: Giant AM 29", Tubeless ready
Hubs: Giant eTracker Boost,
Spokes: Stainless steel
Tyres: [F] Maxxis Minion DHF 29X2.50"foldable, TLR, EXO, 60TPI [R] Maxxis Dissector 29X2.40"WT foldable, TLR, EXO, 60TPI

Other
Lock: Torx 25 Battery Lock with built-in Torque limiter

All specifications are subject to change without notice.
