Marin San Quentin 3 27.5 - White-Black - 2023



The San Quentin is for the aggressive hardtail trail rider looking for a blend between singletrack capabilities and extended air time.

Key upgrades over the San Quentin 2:

  • RockShox Revelation RC fork
  • Shimano Deore 6100 wide-range 12-speed drivetrain
  • Shimano MT420 4-piston brakes
  • Maxxis Assegai 3C MAXX TERRA EXO tubeless compatible tires

TECHNOLOGY

SERIES 3 AND 2 ALUMINUM FRAMES
The San Quentin 1 features a Series 2 aluminum frame, with tapered head tubes, 3D forged drop outs, IS brake mounts, and semi-internal cable routing. The San Quentin 2 and 3 feature Series 3 aluminum frames, with more advanced tube forming, more complex dropouts, post mount disc tabs, full internal cable routing, and a boost 148mm thru-axle

DIRT JUMP INSPIRED FRAME STYLE
Taking cues from the Alcatraz, the San Quentin line up provides all the benefits of the DJ style with massive stand over, slick frame tubes, and a sexy paint job.

MODERN TRAIL GEOMETRY
The slack head tube angle paired with a steep seat tube angle create a ride that will fly uphill with perfect front wheel precision but then descend like it’s on rails. The balanced rider position thanks to the steep seat tube puts your weight between the wheels for impressive climbing and handling on flats, while the slack front end and short rear center help to pull you through the rough descents and corners with an intuitive feel.

ISCG TABS
San Quentin 2 and 3 models feature ISCG 05 tabs for easy chain retention device installation for rowdier riders.

keyboard_arrow_right Specifications

  • FRAME: All New Series 3 6061 Aluminum, Double Butted Frame, Internal Cable Routing, 12x148mm Thru-Axle, 73mm Threaded BB
  • FRONT SUSPENSION: Marzocchi Bomber Z2, 110x15mm Boost Spacing, 140mm Travel, Kabolt Axle
  • RIMS: Marin Aluminum Double Wall, Disc Specific, 29mm Inner, Sleeved Joint, 32H, Tubeless Compatible
  • HUB, REAR: Shimano HB-MT410B, 148x12mm, Disc, Microspline Freehub Body
  • HUB, FRONT: Shimano HF-MT410B, 110x15mm, Disc
  • SPOKE, NIPPLES: 14g Black Stainless Steel
  • TIRES: Vee Tire Co Attack HPL, 29x2.5", Top 40 Tubeless Compatible
  • DERAILLEUR, REAR: Shimano Deore, 12-Speed, SGS
  • SHIFT LEVER: Shimano Deore, 12-Speed, SL-7100R
  • CRANKSET: FSA Comet, Modular 1x, 32T Direct Mount Chainring, MegaTooth Technology, Boost Spacing
  • BOTTOM BRACKET: Mego EXO 73mm BSA
  • CHAIN: KMC X-12 Silver and Black
  • CASSETTE: Shimano, Deore 12-Speed, 10-51T
  • BRAKE, FRONT: Shimano MT420, 4-Piston Hydraulic Disc Brake, Metallic Pads, 203mm Rotor
  • BRAKE, REAR: Shimano MT420, 4-Piston Hydraulic Disc Brake, Metallic Pads, 180mm Rotor
  • BRAKE LEVERS: Shimano MT4100 Hydraulic Lever, I-Spec EV Compatible
  • HANDLEBAR: Marin Mini-Riser, 6061 Double Butted Aluminum, 780mm Width, 28mm Rise, 5º Up, 9º Back
  • STEM: Marin 3D Forged Alloy, 35mm
  • GRIPS: Marin Grizzly Lock On
  • HEADSET: FSA No 57E, Semi-Sealed Cartridge Bearings, 1 1/8" x 1 1/2”
  • SEATPOST: X-Fusion Manic, 1x Composite Remote, Size S 125mm Travel, All Other Sizes: 150mm Travel, 30.9mm
  • SADDLE: Marin Speed Concept
  • PEDALS: Nylon Platform

Specifications, pricing, and availability are subject to change without notice.
