Haro Flightline 24" Plus Disc Kids Bike - Cool Gray
Haro Flightline 24" Plus Disc Kids Bike - Cool Gray
Product ID: GM071425-07
Shop all Haro | Shop all Kids Bikes
View full detailsDescription
Haro Flightline 24" Plus Disc Kids Bike
The Haro Flightline 24 Plus Disc Mountain Bike is crafted for young riders seeking adventure on the trails, Packed with additional features making this build a dependable and comfortable ride for young adventurers.
Featuring a robust FL 24" Plus X6 Series frame with new chainstays and a 6000 Series aluminum fork. It boasts an efficient aluminum 3-piece 32T crankset with a double chainguard, smooth shifting from a Shimano Altus 8-speed rear derailleur, and Shimano SL-M315-R Rapid Fire shifter.
Rolling on Chao Yang H5183 20"x2.60" tires and aluminum single wall 20" rims, the bike ensures excellent stability and traction. Stopping power is provided by Tektro HD-J285 hydraulic disc brakes with 160mm rotors and kid-specific brake levers.
Features:
- FL 24" Plus X6 Series frame, new chainstays
- 6000 Series aluminum 1-1/8" fork
- Aluminum 3-pc 28T crankset w/ double chainguard
- Shimano Altus 8-SPD, Rear Derailleur
- Chao Yang H5183 24"x2.60"
- Tektro HD-J285 Hydraulic disc brakes with 160mm rotors and short reach levers
- Alloy Riser Bar, 620mmW, 9° back sweep, 25mm Rise, ø31.8
Specifications:
| Frame | FL 24" Plus X6 Series frame, new chainstays |
|---|---|
| Fork | 6000 Series aluminum 1-1/8" fork |
| Colors | Cool Grey |
| DRIVETRAIN | |
| Cranks | Aluminum 3-pc 32T crankset w/ double chainguard |
| Pedals | MTB nylon body 9/16" |
| Chain | KMC Z8 8.3, 1/2"x3/32", 92L, GYGY |
| Bottom Bracket | Cartridge Bearing 73mmX122.5mm |
| Front Derailleur | N/A |
| Rear Derailleur | Shimano Altus 8-SPD, RD-M310-L |
| Derailleur Shifter | Shimano SL-m315-r rapid fire 8spd |
| Freewheel/Cassette | Shimano cs-hg200-8 12-32T |
| WHEELS | |
| Tires | Chao Yang H5183 20"x2.60" |
| Wheels/Rims | Aluminum single wall 20" 31mm wide |
| Front Hub | Steel 6 bolt rotor compatible |
| Rear Hub | Steel 6 bolt rotor compatible |
| BRAKING SYSTEM | |
| Brakes | Tektro HD-J285 Hydraulic disc brakes with 160mm rotors |
| Brake Levers | Kids specific Tektro HD-J285 brake levers |
| OTHER COMPONENTS | |
| Grips/Tape | Krayton rubber 127mmL |
| Handlebar | Alloy Riser Bar, 620mmW, 9° back sweep, 25mm Rise, ø31.8 |
| Stem | Alloy 1-1/8", ø31.8 bar bore, 45mmL, 7° Rise |
| Headset | 1-1/8" Threadless |
| Saddle | Haro Flightline Jr |
| Seat Post | Alloy micro adjust ø27.2 |
| Seat Clamp |
Alloy ø31.8 quick release |
Geometry:
| SIZE | 24 |
|---|---|
| Seat Tube (C-T) | 305mm (12") |
| Top Tube (Effective) | 512mm (20.2") |
| Head Tube Angle | 69° |
| Seat Tube Angle | 73° |
| Chainstay Length | 415mm (16.3") |
| BB Drop | 45mm (1.8") |
| Wheelbase | 987mm (38.9") |
| Head Tube Length | 90mm (3.5") |
| Standover | 615mm (24.2") |
| Stack Height | 499mm (19.6") |
| Reach | 360mm (14.2") |
| Axle to Crown | 407mm (16") |
| Fork Offset | 35mm (1.4") |
| Stem Length | 45mm |
| Bar Width | 620mm |
| Crank Length | 152mm |
| Wheel Size | 24 |
Sizing Guide:
| Size | Inches | CM |
|---|---|---|
| 24 | 4' - 4'8" | 122 - 142 |
